Product Overview
High-Speed Wide-Web Slitting Equipment converts wide parent rolls into multiple finished rolls through continuous unwinding, web guiding, slitting and rewinding. It is used for films, paper, foil and other flexible web materials where finished width, roll diameter, winding condition and production speed must match the downstream process.
Material Compatibility
PET, BOPP, PE, CPP and similar films can be processed according to thickness, elasticity, surface condition and winding behavior.
Kraft paper, aluminum foil, metallized films and selected coated materials can be processed with tension and cutting settings matched to the substrate.
Material thickness, parent-roll weight, coating, stiffness and surface condition should be confirmed before the final equipment specification is set.
Slitting Configuration
Slit Width
Knife positions are arranged according to finished-roll width and lane quantity. The minimum practical slit width depends on material thickness and knife arrangement.
Knife Selection
Razor or circular-knife systems can be selected according to substrate structure, thickness and required slit edge.
Edge Trim
Trim collection is arranged around the slit layout and web width to maintain a clear material path during continuous operation.
Tension and Web Control
Unwind Tension
The unwind section maintains controlled web tension as the parent-roll diameter reduces during production.
Web Guiding
Automatic web guiding corrects lateral web movement before the material enters the slitting section.
Rewind Tension
Rewind tension is matched to material thickness, slit width, roll diameter and required finished-roll hardness.
Rewinding Requirements
Finished Roll Diameter
The rewind section is selected according to the required finished-roll diameter and production length.
Core Size
Typical core diameters include 76 mm and 152 mm. Other core dimensions can be specified according to the finished-roll format.
Roll Formation
Rewind pressure and tension settings determine roll build, edge alignment and finished-roll hardness for downstream handling.
Production Applications
Flexible Packaging
Wide film rolls can be converted into narrower reels for printing, laminating, bag making and packaging operations.
Paper Converting
The equipment processes wide paper rolls into specified widths for subsequent converting, printing or packaging processes.
Industrial Web Processing
Selected foil, metallized and coated web materials can be slit into production widths for further processing.
Key Equipment Benefits
High-Speed Processing
The continuous web path supports production where wide parent rolls must be converted into multiple finished rolls within a controlled process.
Controlled Slitting
Adjustable knife positioning establishes the required finished widths across the selected number of lanes.
Consistent Rewinding
Tension and rewind pressure are coordinated to produce finished rolls with controlled winding condition.
Production Flexibility
Working width, knife layout, core arrangement and rewind dimensions can follow different material and finished-roll requirements.
Technical Specifications
|
Parameter |
Reference Specification |
|
Working Web Width |
1,300–2,500 mm |
|
Maximum Unwind Diameter |
800–1,200 mm |
|
Maximum Rewind Diameter |
500–800 mm |
|
Maximum Line Speed |
Up to 500 m/min |
|
Minimum Slit Width |
From 20 mm |
|
Core Diameter |
76 / 152 mm |
|
Slitting Method |
Razor / Circular Knife |
|
Web Tension |
Material-dependent |
|
Material Thickness |
Material-dependent |
|
Control System |
PLC-based |
Project Selection
Parent Roll Data
Confirm parent-roll width, diameter, core size, material thickness and maximum roll weight before equipment selection.
Finished Roll Data
Provide finished widths, lane quantity, rewind diameter, core size and required roll hardness.
Production Target
Specify target operating speed, production volume and working hours together with the material and finished-roll data.
Material Data
Material samples or complete technical specifications help determine knife selection, tension settings and rewind requirements.
Manufacturing and Quality Control
Production Facility
Manufacturing covers sheet metal, cutting, mechanical assembly and testing across a production facility of approximately 5,000 m² with 13+ workstations.
Technical Team
More than 40 skilled professionals support mechanical production, electrical integration, assembly and equipment testing.
Quality Management
Production follows controlled quality procedures. ISO 9001 certification and CE conformity are available for applicable equipment configurations.
FAQ
Q: What materials can this equipment process?
A: It can be configured for films, paper, aluminum foil, metallized films and selected coated web materials. Final suitability depends on thickness, stiffness, coating and winding behavior.
Q: How is the required working width determined?
A: Working width is based on parent-roll width, finished slit widths, lane quantity and required trim allowance.
Q: What determines the operating speed?
A: Operating speed depends on material characteristics, slit width, lane quantity, roll diameter, tension requirements and finished-roll specifications.
Q: What information is required for a quotation?
A: Provide material type and thickness, parent-roll width and diameter, core size, finished widths, lane quantity, rewind diameter and target operating speed.
Q: Can different finished-roll specifications be processed?
A: The equipment can be specified with different knife layouts, tension settings, rewind dimensions and core arrangements to match the production program.
